Products Description
Multi Deck Vibrating Screen is designed to maximize screening efficiency. Suitable for a variety of applications including mining, construction and recycling, materials can be accurately sorted by size.
item
|
Multi Deck Banana Vibrating Screen Ore Classifier Retangular Mechanical Sieve
|
Applicable Industries
|
Manufacturing Plant, Construction works , Energy & Mining, Other
|
Showroom Location
|
South Africa, Australia
|
Video outgoing-inspection
|
Provided
|
Machinery Test Report
|
Provided
|
Marketing Type
|
New Product 2021
|
Warranty of core components
|
1 Year
|
Core Components
|
Motor, exciter
|
Condition
|
New
|
Type
|
banana vibrating screen
|
Application
|
Ore
|
Place of Origin
|
China
|
Brand Name
|
TSX
|
Voltage
|
380V;660V
|
Dimension(L*W*H)
|
9438*6122*5837
|
Weight
|
59280KG
|
Warranty
|
1 Year
|
Feature
|
High Screening Efficiency
|
capacity
|
>1400t/h
|
Material
|
Q235B
|
Delivery Time
|
35days
|
Layer(s)
|
2 Layers
|
Color
|
costomized
|
Surface treatment
|
Paint
|
MOQ
|
1set
|
Usage
|
Separation Screening
|
Banana Screens Technical Data
|
|||||||
Model
|
Layer
|
Model of screen deck
|
Power(kw)
|
Capacity(t/h)
50mm |
Feed size (mm)
|
Weight(t)
|
Overall dimension(mm)
|
ABS1848
|
1
|
1800×4800mm
|
1*18.5kw
|
>200
|
0-300mm
|
6.583
|
5651*2630*2714
|
ABS1861
|
1
|
1800×6100mm
|
1*22kw
|
>260
|
0-300mm
|
7.208
|
6833*2610*2818
|
ABS2461
|
1
|
2400×6100mm
|
1*22kw
|
>300
|
0-300mm
|
8.067
|
6853*3216*2786
|
ABS3061
|
1
|
3000×6100mm
|
1*30kw
|
>350
|
0-300mm
|
11.1
|
6862*3870*2847
|
ABS3661
|
1
|
3600×6100mm
|
1*30kw
|
>450
|
0-300mm
|
13.004
|
6867*4500*2895
|
ABS4261
|
1
|
4200×6100mm
|
1*55kw
|
>600
|
0-300mm
|
19.619
|
6895*5140*3482
|
ABS4985
|
1
|
4900×8500mm
|
1*90kw
|
>900
|
0-300mm
|
29.979
|
9093*5730*4280
|
ABD1848
|
2
|
1800×4800mm×2
|
1*22kw
|
>350
|
0-300mm
|
10.933
|
5567*2536*3786
|
ABD3061
|
2
|
3000×6100mm×2
|
1*55kw
|
>400
|
0-300mm
|
11.981
|
6852*3870*3907
|
ABD3661
|
2
|
3600×6100mm×2
|
1*55kw
|
>500
|
0-300mm
|
23.616
|
6929*4500*4095
|
ABD4985
|
2
|
4900×8500mm×2
|
2*90kw
|
>1400
|
0-300mm
|
59.280
|
9438*6122*5837
|
Note: The mesh size can be customized as your request. The layer also can make as your requirement.
|
Tags:
Technical parameter
.jpg)
RDQ Series Vibration Exciter

RDQ Series Vibration Exciter

SKF Vibration Bearings
TSX SCREEN high efficiency exciter mounted on the specialized SKF vibrating bearing with the advantage of strong exciting power, lower noise and longer working life.
